nBox Recorder

Capture, record and reproduce your network traffic with nBox Recorder!

nBox Recorder is a network traffic recording system.

Available Models

The nBox Recorder is available in several models, listed in the following table.

info & prices
nbox@hostingsolutions.it

Form Factor: 1U 19" rack-mount
Monitoring Ports: 2 x 10 Gbit Intel ZC SFP+
Certified Dump Performance: 2 x 10 Gbit/s (2 x 14.88 Mpps)
Storage Size: 8 x 0.96 TB

Compare

info & prices
nbox@hostingsolutions.it

Form Factor: 1U 19" rack-mount
Monitoring Ports: 2 x 40 Gbit FPGA-based adapter with Hardware Timestamps (QSFP28)
Certified Dump Performance: 2 x 10 Gbit/s (2 x 14.88 Mpps)
Storage Size: 8 x 1.6 TB

Compare

info & prices
nbox@hostingsolutions.it

Form Factor: 2U 19" rack-mount
Monitoring Ports: 1 x 100 Gbit FPGA-based adapter with Hardware Timestamps (QSFP28)
Certified Dump Performance: 100 Gbit/s line rate
Storage Size: 8 x 1.6 TB

Compare

The price of nBox products is not shown as it strictly depends on the configuration required and the destination of the delivery.

With nBox Recorder you can capture full-sized network packets at gigabit rate from a live network interface and write them into files. It has been designed and developed mainly because most network security systems rely on capturing all packets (headers and payload), since any packets may have been responsible for the attack or could contain the problems that we are trying to find.

nBox Recorder uses the industry standard PCAP file format to dump packets into files so the resulting output can be easily integrated with existing third party or even open-source analysis tools like ntopng, Wireshark or Snort.

nBox Recorder can be effectively used to perform:

  • Off-line network packets analysis by feeding a specialised tool (such as snort or ntopng).
  • Reconstruct specific communication flows or network activities.
  • Reproduce the previous captured traffic to a different network.

Main Features

The main nBox Recorder features are:

  • 10/40/100 Gbit/s packet to disk with zero packet loss in PCAP file format
  • On-the-fly indexing and compression with DPI visibility and encrypted traffic detection
  • Flexible traffic shunting
  • Web configuration and management
  • API accessible search indexes
  • PCAP re-injection into network.Appliance available in 1U or 2U form factor, with on storage size, over 1 PB
  • Extended PCAP analysis immediately available using the ntopng web-based analyser
